YIJIANG specialize in designing track undercarriage manufacturing.



Our undercarriage is composed of track roller,top roller,idler,sprocket,tension device rubber track or steel track etc, it is manufactured with the latest domestic technology, featuring compact structure, reliable performance, durability, convenient operation and low energy consumption. It is widely used in various drilling, mine machinery, fire-fighting robot, underwater dredging equipment ,aerial working platform, transport lifting equipment, agricultural machinery, garden machinery, special working machinery, field construction machinery, exploratory machinery, loader, static detection machinery, gadder , anchor machinery and other large, medium and small machinery.



Undercarriage is divided to steel track and rubber track undercarriage. Steel track undercarriage’s carrying capacity is 1 ton-150 ton, rubber track undercarriage’s carrying capacity is 0.2 ton-30 ton.



We not only can provide professional undercarriage selection and design service according to the customer's different equipment working requirements; but also can recommend to use the corresponding motor and drive equipment to facilitate customers to install at one time.





One-Stop Solution

YIJIANG company is specialized in manufacturing crawler undercarriage, including engineering machinery undercarriage, skid steer loader undercarriage, agricultural machinery undercarriage, garden machinery undercarriage and the matched spare parts: track roller, top roller, sprocket, idler and rubber track.



Related Products



1. We are manufacturer , belong to the integration of industry and trade.

2. Our company has independent design capability and team.

3. Our company has a complete set of processing methods, processing center.

4. Our company's product series are complete: from track roller, sprocket, top roller, front idler, rubber track, steel track to undercarriage, we can design and customize special mechanical equipment.

5. Our company has a strong R&D platform.









Main Product



YIJIANG undercarriage is widely used in various mobile crusher, drilling, mine machinery, fire-fighting robot, underwater dredging equipment ,aerial working platform, transport lifting equipment, agricultural machinery, garden machinery, special working machinery, field construction machinery, exploratory machinery, loader, static detection machinery, gadder , anchor machinery and other large, medium and small machinery.











Professional customized undercarriage

Based on the manufacturing and design experience of the undercarriage, the company has developed the rubber track undercarriage and steel track undercarriage, which are widely used in various construction machinery, drilling, fire fighting robot, underwater dredging equipment and other special working machinery.

Our company can customize track undercarriage,such as anchor drilling rig, water well drilling rig, core drilling rig, jet drilling rig, down-hole drilling rig, hydraulic crawler



drilling rig, multipurpose drilling rig, etc





Undercarriage description

1. Complete with rubber track,steel track, track link,final drive,hydraulic motors rollers and crossbeam.

2. Loading capacity from 0.5 T to 150T.

3. We are professional to design the whole undercarriage according to customers' different requirements.

Track undercarriage parameters



Type	Parameters(mm)					Track Varieties	Bearing(Kg)
	A(length)	B(center distance)	C(total width)	D(width of track)	E (height)
SJ050	1200	900	900	150	300	rubber track	500
SJ080	1240	940	900	180	300	rubber track	800
SJ100	1380	1080	1000	180	320	rubber track	1000
SJ150	1550	1240	1000	200	350	rubber track	1300-1500
SJ200	1850	1490	1300	250	400	rubber track	1500-2000
SJ250	1930	1570	1300	250	450	rubber track	2000-2500
SJ300A	2030	1500	1600	300	480	rubber track	3000-4000
SJ300B	1895	1500	1700	300	485	steel track	3000-4000
SJ400A	2166	1636	1750	300	520	rubber track	4000-5000
SJ400B	1990	1600	1800	300	530	steel track	4000-5000
SJ500A	2250	1720	1800	300	535	rubber track	5000-6000
SJ500B	2118	1591	1800	300	550	steel track	5000-6000
SJ700A	2812	2282	1850	350	580	rubber track	6000-7000
SJ700B	2795	2265	1800	350	600	steel track	6000-7000
SJ800A	2880	2350	1850	400	580	rubber track	7000-8000
SJ800B	2880	2350	1850	400	600	steel track	7000-8000
SJ1000A	3500	3202	2200	400	650	rubber track	9000-10000
SJ1000B	3500	3202	2200	400	670	steel track	9000-10000
SJ1500A	3800	3802	2200	500	700	rubber track	13000-15000
SJ1500B	3800	3802	2200	400	700	steel track	13000-15000
SJ2000B	3805	3300	2200	500	720	steel track	18000-20000
SJ2500B	4139	3400	2200	500	730	steel track	22000-25000
SJ3500B	4000	3280	2200	500	750	steel track	30000-40000
SJ4500B	4000	3300	2200	500	830	steel track	40000-50000
SJ6000B	4500	3800	2200	500	950	steel track	50000-60000
SJ8000B	5000	4300	2300	600	1000	steel track	80000-90000
SJ10000B	5500	4800	2300	600	1100	steel track	100000-110000
SJ12000B	5500	4800	2400	700	1200	steel track	120000-130000
SJ15000B	6000	5300	2400	900	1400	steel track	140000-150000



Track undercarriage aplplication scenarios



Our company has a complete design and production team, so we can design and manufacture a variety of crawler track undercarriage according to the different requirements of customers.





Track undercarriage packing



Packaging of front idler : Standard wooden pallet or steel pallet.

Mode of Transportation: ocean shipping, air freight, land transportation.





FAQ



Q1. If your company a trader or manufacturer?

A : We are the manufacturer & trader .

Q2. Can you supply customize undercarriage?

A : Yes. We can customize the undercarriage according to your requirements.

Q3. How is your price?

A : We guarantee the quality while providing the right price for you.

Q4. How is your after – sale service?

A : We can give you one year after sales warranty, and any quality problem caused by manufacturing defects can be unconditionally maintained.

Q5. What is your MOQ?

A : 1 set.

Q6. How will you place your order?

A : In order to recommend a suitable drawing and quotation to you , we need to know:

a. Rubber track or steel track undercarriage, and need the middle frame.

b. Machine weight and undercarriage weight.

c. Loading capacity of the track undercarriage ( the weight of the whole machine excluding of track undercarriage.

d. Undercarriage’s length, width and height

e. Track’s Width.

f. Height

g. The max speed (KM/H).

h. Climbing slope angle.

i. The machine’s apply range , working environment.

j. Order quantity.

k. Port of destination.

l. Whether you require us to purchase or collocate relevant motor and gear box or not, or other special request.
